JYS9765L
Dimensional 轮廓图 unit:mm
SPECIFICATIONS 规格
Sensitivity: (0dB=1V/Pa.1KHz)
-38±3dB | -40±3dB |
-42±3dB | -44±3dB |
| -46±3dB | -48±3dB |
高灵敏度 | -29±3dB |
Directivity: Omnidirectional
Standard Operation Voltage:1.5V
Output Impedance:＜1.5KΩ
Current Consumption:Max.0.5Ma
Sensitivity Reduction:Within -3dB at 1.5V
S/N Ratio:More than 58dB
Schematic Diagram 测试电路图
Typical Frequency Response Curve 频率响应曲线
Appearance 外观图
JYS
